After the PKI: Migrating mnemosyne to mTLS

The Loop to Close

#

In the previous post I covered the PKI project certification: five destroy+create cycles, the Root CA in VSO templates, the fixed Grafana HelmRelease, and the first working mTLS case with Grafana connecting to PostgreSQL via client certificate.

But Grafana was a special case. It uses a web framework (Go), sure, but the configuration is all Helm YAML — no code to write. The real challenge was the cluster’s only custom Go application: mnemosyne-mcp-server, an MCP server for semantic memory (vector embeddings with pgvector and Gemini).

Its db.go hardcoded sslmode=disable and required DB_PASS as mandatory. Until yesterday, it was the last client on password auth.

The PKI Project Had Already Done Everything

#

One of the advantages of building the PKI project with the CRISP methodology — mandatory research, verified design, structured reviews — is that by the time you reach the client application implementation, the road is already paved.

The VaultPKISecret for mnemosyne (db-client-mnemosyne-tls) already existed, with a 24h TTL and VSO templates generating tls.crt, tls.key, and ca.crt (with the full three-tier chain: Tier 2 + Tier 1 + Root CA). The Vault role db-client-mnemosyne was already configured on pki_int. PostgreSQL (PGO v5.7.2) already had pg_hba rules to accept client certificate connections.

Only the app was missing: it needed to learn how to use those certificates.

The Go Refactor: Simple, with One Subtle Point

#

The code change was straightforward. I added an SSLConfig to db.go:

type SSLConfig struct {
    SSLMode     string
    SSLCert     string
    SSLKey      string
    SSLRootCert string
}

func New(host, port, user, password, dbname string, ssl *SSLConfig) (*DB, error) {

The nil pointer maintains backward compatibility: when ssl is nil, the connection uses sslmode=disable as before. When an SSLConfig with SSLMode != "" is provided, it builds the connection string with the TLS parameters.

The env side (main.go) was equally simple: read DB_SSLMODE, DB_SSLCERT, DB_SSLKEY, DB_SSLROOTCERT from environment variables and make them optional. The real novelty was making DB_PASS non-mandatory when using an SSL mode that requires certificate authentication:

if dbPass == "" && dbSslMode != "require" && dbSslMode != "verify-ca" && dbSslMode != "verify-full" {
    missing = append(missing, "DB_PASS")
}

This small change was a sensitive point during the reviews: it’s easy to fall into the trap of only handling verify-full (the most secure mode) and forgetting that require and verify-ca exist — less secure but useful in specific contexts, such as debugging or integrating with services that don’t support hostname verification. Three reviews on this project circled around this subtlety, and each time the condition was widened until it covered all modes.

defaultMode: 384

#

The Kubernetes deployment mounts the db-client-mnemosyne-tls secret into /etc/secrets/tls with defaultMode: 384 — which corresponds to 0600 in octal. The lib/pq library (like all PostgreSQL libraries) rejects the private key if it’s readable by others. It’s a detail I already encountered with Grafana, and it’s worth keeping in mind: overly permissive permissions on tls.key are the most common mistake in mTLS configurations.

Automatic Rotation: A Test Worth Doing

#

The mnemosyne client certificate has a 24h TTL. VSO (Vault Secrets Operator) renews it approximately every 20 hours (TTL - 4h expiryOffset). The VaultPKISecret has rolloutRestartTargets pointing to the mnemosyne deployment: when the secret changes, the deployment is reconciled and the pod restarts with the new certificate.

To verify the mechanism worked, I forced a rotation by deleting the Kubernetes secret. VSO regenerated it in about 5 seconds, and the pod was replaced automatically (new ReplicaSet, not a simple restart). The certificate serial changed — and the PostgreSQL connection remained active. pg_stat_ssl showed ssl=t, client_dn=/CN=mnemosyne both before and after.

I also tested backward compatibility: I temporarily removed the SSL variables from the deployment, leaving only DB_PASS. The pod reconnected via password. pg_stat_ssl showed ssl=f, client_dn=null. It worked. Then I restored the SSL variables and permanently removed DB_PASS and the md5 rules from pg_hba.

Problems Encountered

#

The project was surprisingly clean — especially compared to the five PKI cycles. There were only two real issues:

YAML Indent

#

The dumbest one. I had added rolloutRestartTargets to the VaultPKISecret before the transformation block. YAML has precise indentation rules: after a mapping key that contains a sequence (the restart targets), you can’t go back to the same indentation with a new key. Flux’s parser reported it with a cryptic did not find expected '-' indicator. I moved it after the transformation block — at the same indentation as destination — and it worked.

Slow Flux Reconciliation

#

The kustomization containing mnemosyne’s resources (infrastructure-instances) is at the bottom of a four-level dependency chain: from infrastructure-operators-vso up to infrastructure-configs and down to infrastructure-instances. Each level must be Ready=True before the next one can execute. After the Git push, I had to manually trigger reconciliations to speed up the process — otherwise it would take several minutes for the full propagation. Not a bug, but a standard Flux behavior worth knowing when working with deep dependency chains.

pg_stat_ssl: The Proof

#

The final verification was the most satisfying:

 usename  | ssl |   client_dn
----------+-----+---------------
 mnemosyne | t   | /CN=mnemosyne

ssl=t means the connection is encrypted with TLS. client_dn=/CN=mnemosyne means PostgreSQL verified the client certificate, extracted the Common Name, and accepted it. No password. No DB_PASS in the configuration. Just the certificate signed by Vault PKI.

What’s Left

#

With mnemosyne migrated, the PostgreSQL app landscape looks like this:

The next two migrations (pgAdmin and Vault DB engine) are already planned as separate CRISP projects. But they have a different complexity level: pgAdmin requires managing a preconfigured servers.json file with certificate paths; the Vault DB engine requires a Vault Agent sidecar on the Hetzner VM, an enterprise HashiCorp pattern I’ve never implemented before.

For now, though, the PKI project loop — started with the goal of eliminating static passwords from all database connections — has gained another notch. Two apps out of five. Three still to go. But the pattern is now well-established.

This article is part of a series on TazLab infrastructure management. Previous posts: Vault PKI Follow-Up, PKI Vault on TazLab. Code on github.com/tazzo.
